Quick Details

  • Condition: New
  • Type: Horizontal
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Hunkui
  • Model Number: H45
  • Voltage: 220V/380V
  • Power(W): 7.5/11kw
  • Dimension(L*W*H): 2800*1800*2450mm
  • Weight: 4500kg
  • Certification: ISO9001 CE
  • Warranty: 1 Year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Machine Type: punching machine tooling
  • Worktable Size: 400*800mm
  • Max. Load Capacity: 400kg
  • X-axis Travel: 650
  • Y-axis Travel: 550mm
  • Z-axis Travel: 500mm
  • Controlling Mode: Cnc Control
  • Spindle Speed: 8000rpm
  • X/Y/Z Rapid Speed: 30m/min
  • X/Y/Z axis Ball Screw: Taiwan,40*12

Packaging & Delivery

Packaging Details Wooden Package for Controlled Chip Conveyor CNC Horizontal Milling Machining Center
Delivery Time 15~45 Day for CNC Horizontal Milling Machining Center
Product Description

The casting wood of the lathe adopts with the casting of aluminum wood and the resin sand mould. The workbench is the type of HT300, and the rest are the type of HT250. After twice artificial aging treatment, it has the good stability and high intensity, and the precision is stable and reliable.
The lathe chooses the spindle specifications for BT50, diameter is 190 mm.

The characteristics

◇The main motor is located in the center of the spindle box, so the stress and the thermal deformation is symmetrical, and it also has a good thermal stability.
◆Large torque:

BIIP30, which can guarantee the high torque at low speed and high constant power range.
◆Compared with the same specification lathe, it is of large processing range and small covering area.


Our Company

Jinan Hankui international trade co., ltd

     Jinan Hankui international trade co., ltd, which is the subsidiary corporation of Shandong Hunk precision machinery Co., Ltd., is a CNC machine tools company, located in the beautiful capital Jinan city, integrated with manufacturing, processing and sales. It was set up by the former Jinan Machine tools factory employees. It has a subsidiary corporation Jinan HANKUI International Trade Co., Ltd. The plant area is about 10,000 square meters. We have a number of R&D persons and technicians who have more than 20 years experience of machine tool design and assembly. We have mastered the advanced machine tool technology and were dedicating to service customers domestic and abroad and welcomed deeply.

Factory

Our Factory

Workshop

Our Workshop

Warehouse

Our Warehouse

Team

Our customers

The main products are horizontal / vertical/ gantry machining center, flat / slant bed CNC tuning lathe, CNC vertical turning lathe etc. With superior equipment, advanced technology, detection devices, the imported parts from Taiwan, Japan, Germany etc., we can manufacture the high quality machine tools. And we also take over the metal products and spare parts machining in good quality.

FAQ

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available, We need your machines running in order to keep your business running.

Q: Once we've bought a machine from you, are you able to supply us with material?
A: We can assist you in finding the appropriate materials to suit your machine

Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.OEM is acceptable

Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.

Q: What sales terms do you have?
A:T/T, L/C,West Union.

Q: Do you have instruction manuals?
A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings or Video Support,


Q: Once  machine arrives at our factory what happens then?
A: We will send you a technician or engineer that will commission and install your machine, with training for your staff if required at a separate fee.

Q: What do I need to offload my machine from the container?
A: You are not responsible for the offloading of your machinery, and it is recommended that you use a reputable rigging company.

Q: What kind of controls/Parts do you use on your machines?
A: AMS, OMRON, Schneider, Siemens, and ASK,ABBA,OPTIMA(ITALIA),HSD

Q: What is your delivery time?
A: Depending on the type of machine, duration of 10 days to 45 days from date of order.

Q:  Do we receive any updates while machine is in the manufacturing process?
A: Yes.Regular updates on progress will be sent to you.

Technical parameter
ITEM
H45
H45-1
H45-2
H45-3
Worktable size
450×450mm
450×450mm
450×450mm
450×450mm
Worktable quantity
1
2
1
2
Indexing unit
1°X360
1°X360
0.001°
0.001°
Max. load
400kg
400kg
400kg
400kg
Max. workpiece swing dia
700mm
600mm
700mm
600mm
X axis travel
600mm
600mm
600mm
600mm
Y axis Headstock travel
550mm
550mm
550mm
550mm
Z axis column travel
550mm
550mm
550mm
550mm
Spindle speed (BT50)
8000rpm
8000rpm
8000rpm
8000rpm
Spindle center line to table surface
110~660mm
0~550mm
110~660mm
0~550mm
Distance between spindle nose to table center
100~650mm
100~650mm
100~650mm
100~650mm
Spindle servo motor
11KW
11KW
11KW
11KW
Rapid speed  (X, Y, Z axis)
40m/min
40m/min
40m/min
40m/min
                         (B axis )
10r/min
10r/min
15r/min
15r/min
Positioning accuracy (X, Y, Z axis)
0.01
(total travel)
0.01
(total travel)
0.01
(total travel)
0.01
(total travel)
                                          (B axis )
10″
10″
10″
10″
Re-positioning accuracy (X, Y, Z axis)
0.006
(total travel)
0.006
(total travel)
0.006
(total travel)
0.006
(total travel)
                                                 (B axis )
5″
5″
5″
5″
Dimension
3000*1900*2550mm
3700*1900*2550mm
3000*1900*2550mm
3700*1900*2550mm
G.W
5500kg
6500kg
5500kg
6500kg
Main components
The serial number
Name
Model or drawing No.
Origin
QTY
Note
1
The top
Domestic
1 set
2
X screw pair to the ball
2505
Taiwan
1 pair
3
Z screw pair to the ball
3210/P3
Taiwan
1 pair
4
Angular contact ball bearings
NSK
1 set
With screw
5
X, Z line rail
Taiwan
6
Angular contact ball bearings
NSK
2set
With screw
7
Double grinding coupling
domestic
2 set
8
Cooling pump
domestic
1 set
9
Lubrication system
domestic
1 set
Packing & Delivery

Packing Details  : Packing by woodenbox or depend on request

Delivery Details : 7-45 days
